Artikel-Nr: C600510C003A
Artikel-ID: 29597

Produktinformationen
Das Cambium Networks cnWave 60GHz Building-to-Building 1GB Link-Set bietet eine zuverlässige und kosteneffiziente Lösung für Unternehmen, die eine Hochleistungs-Punkt-zu-Punkt-Verbindung zwischen zwei Standorten benötigen. Mit der fortschrittlichen 60GHz-Technologie ermöglicht dieses Link-Set Gigabit-Geschwindigkeiten und eine stabile Verbindung, ideal für bandbreitenintensive Anwendungen.
Alle Zubehörteile sind im Lieferumfang enthalten.
Technische Daten
| Artikel | C600510C003A |
| Carrier Bonding | Up to 2 adjacent channels |
| Frequency Range | 57 to 66 GHz in a single SKU |
| Channel Width | 2.16 GHz, 4.32 GHz* |
| Mode of Operation | PMP or Mesh, PTP* |
| Channel Access | TDMA/TDD |
| Ethernet Interface | 1x 100/1000 BaseT with PoE In |
| Protocol Supported | IPv4, IPv6 |
| Network Management | cnMaestro, HTTP, HTTPS, SNMP v2c & v3 |
| MTU | 4,000 bytes |
| VLAN | 802.1ad (QinQ), 802.1Q with 802.1p priority |
| QoS* | 4 Level QoS, DSCP and VLAN Tag |
| Encryption | 128-bit AES |
| Firmware Security | Signed Firmware Images |
| Latency | < 1 ms |
| Modulation & Coding Schemes | MCS-0 (BPSK) to MCS-12 (16-QAM) |
| Maximum EIRP | 38 dBm |
| Gain | 22.5 dBi |
| Type | Integrated |
| Beamforming Scan Range | +/- 40º azimuth, +/- 20º elevation |
| Beam Width | 12° |
| Type | 802.3af PoE |
| Power Consumption | 10 W |
| Environmental | IP 66/67 |
| Temperature | -40°C to 60°C |
| Mean Time Between Failure | > 40 years |
| Weight | 0.25 kg |
| Dimensions W x H x D | 140mm x 85mm x 40mm |
| Wind Survival | 200 km/h |
