Ubiquiti UniFi Switch Pro 8 PoE - USW-Pro-8-PoE

Name: Ubiquiti UniFi Switch Pro 8 PoE - USW-Pro-8-PoE -
Brand: Ubiquiti Networks
SKU: 5693
Price: 313.07 EUR
Availability: InStock

8-Port Switch

Layer-3

PoE+- und PoE++-Ausgang

6x GbE PoE+-Ports

2x GbE PoE++-Ports

2x 10G SFP+-Port

Artikel-Nr: USW-Pro-8-PoE

Artikel-ID: 28165

Lagerware - sofort verfügbar

313,07 EUR ^*

* inkl. ges. MwSt. zzgl. Versandkosten Netto 263,08 EUR

Produktinformationen

Ubiquiti UniFi Switch Pro 8 PoE - USW-Pro-8-PoE

Der USW-Pro-8-PoE ist ein 8-Port Switch mit Layer 3 Funktionen und PoE+- und PoE++-Ausgang.

Features

6x GbE PoE+-Ports
2x GbE PoE++-Ports
2x 10G SFP+-Port
insgesamt 120 W PoE-Budger

Technische Daten

Spezifikationen

Eigenschaft	Wert
Artikel	USW-Pro-8-PoE
Größe	200 x 248 x 44 mm
Gewicht	2.1 kg
Materialien	Plastik, Metall
Mount material	Plastik
Management interface	Ethernet In-Band
Networking interface	(8) GbE RJ45 ports (2) 10 Gbps SFP+ ports
PoE interface	(6) PoE/PoE+ (Pins 1, 2+; 3, 6-) (2) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
Total non-blocking throughput	28 Gbps
Switching capacity	56 Gbps
Power method	Universal input, 100—240V AC, max. 2A
Power supply	AC/DC, internal
Supported voltage range	100—240V AC
Max. power consumption	30W (Excluding PoE output)
Total available PoE	120W
Max. PoE wattage per port by PSE	PoE: 15W PoE+: 30W PoE++: 60W
Voltage range PoE mode	PoE: 44—57V PoE+: 50—57V PoE++: 50—57V
LCM display	(1) 1.3" touchscreen
LEDs	RJ45 ports: link/activity
Button	Factory reset
Operating temperature	-5 to 45° C (23 to 113° F)
Operating humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC
